Description
Machine features:
◆Gear shifting, frequency control, wide range of spindle shifting, low speed and high torque
◆The overall bed foot, high rigidity, stable precision
| Machine model | CK6166 |
| Processing range | |
| Maximum workpiece turning diameter on the bed | ￠660mm(26＂) |
| Maximum workpiece turning diameter on the carriage | ￠440mm(17＂) |
| Top distance | 1500mm(59＂) |
| Headstock | |
| Spindle end | D1-8 |
| Spindle through hole diameter | ￠105(4＂) |
| Spindle bore taper | ￠113(1:20)4档/MT5 |
| Spindle speed range | 10~1500 |
| Feed | |
| X-axis travel | 370mm(14-1/2＂) |
| Z-axis travel | 1460mm(57-1/2＂) |
| X-axis fast moving speed | 7500mm/min(295＂/min) |
| Z axis fast moving speed | 9000mm/min(354＂/min) |
| Minimum setting unit | 0.001mm(0.0000349＂) |
| X-direction positioning accuracy | ±0.022mm(±0.00087＂) |
| Z-direction positioning accuracy | ±0.032mm(±0.00126＂) |
| X-direction repeat positioning accuracy | ±0.006mm(±0.00024＂) |
| Z-direction repeat positioning accuracy | ±0.01mm(±0.000394＂) |
| Tool holder | |
| Maximum section of the tool | 25×25mm(1＂×1＂) |
| Tailstock | |
| Tailstock sleeve diameter | ￠90mm(3-1/2＂) |
| Tailstock sleeve stroke | ￠235mm(9-1/4＂) |
| Tail sleeve inner hole taper | No. 5 Morse |
| Motor | |
| Main motor | 7.5kW(10HP) |
| Cooling pump | 0.09kW(1/8HP) |
| Dimensions and weight | |
| Dimensions (length × width × height) | 316×180×175cm |
| Box size (length × width × height) | 329×205×203cm |
| net weight | 3000kg |
| Gross weight | 3400kg |
